Specifications
ER-10X
Dimensions 268.1 x 136.5 x 31.1 mm
(10.55 x 5.37 x 1.22")
Weight 600 g (1.32 lb)
Enclosure Characteristics Metal Housing
Max. Power Consumption 8W
Power Method 24VDC, 1A Power Adapter (Included)
24V Passive PoE
Power Supply External AC/DC Adapter
Passive PoE
Voltage Range
Max. Wattage per Port
DC/PoE Passthrough
15W (24V)
Supported Voltage Range 9 - 30VDC
Button Reset
LEDs
System
RJ-45 Ports
Booting Up (Blue), Powered On
Link / Activity, PoE
Processor MIPS 1004Kc 880 MHz Dual-Core
System Memory 512 MB DDR3
On-Board Flash Storage 512 MB NAND
Operating Temperature -10 to 45° C (14 to 113° F)
Operating Humidity 10 - 90% Noncondensing
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Interfaces
Management
Networking
(1) RJ45 Serial Port
(10) Ethernet Ports (Default Port 0)
(10) 10/100/1000 RJ45 Ports
Port 0 Supports PoE In;
Port 9 Supports PoE Out
Certications CE, FCC, IC
