13
Hi-NCV-Lo
MFD
°F °C
µA
CAT Ill
600V 400A
MAX/MIN
HOLD
Hz / Duty
SELECT
TEMP
DISCONNECT
30V MAX
TESTLEADS
True RMS
DL389B
MAX
CATll1000V
CATIII600V
• Press and hold NCV button, move clamp meter tip near voltage source.
• Non-Contact Voltage Detection is used to detect power with sensor
located in the tip of the clamp head indicates positive response with
both an Audible and Visual alert.
• Do not use non contact voltage detector to determine if there is current
on the wire. Detection operation could be affected by socket design,
insulation thickness, type or other factors.
• Voltage indicator light may also light when voltage is present on the
meter’s input jack or from an external interference such as motors,
flashlights, etc.
Non-Contact Voltage Hi - Lo
NCV
NCV Sensor
located in tip
Temperature °F/°C
Hi-NCV-Lo
MFD
°F °C
µA
CAT Ill
600V 400A
MAX/MIN
HOLD
Hz / Duty
SELECT
TEMP
DISCONNECT
30V MAX
TESTLEADS
True RMS
DL389B
MAX
CATll1000V
CATIII600V
• Default =
• Press x1 =
Features:
WARNING
Disconnect test lead probes from voltage source and meter.
• Press Select button to change between Fahrenheit and Celsius.
Range Resolution Accuracy Overload Protection
-22˚ to 14˚F
(-30˚ to -10˚C)
0.1˚F (0.1˚C)
± (1.0% + 5.4˚F)
± (1.0% + 3.0˚C)
30V RMS
15˚ to 752˚F
(-9˚ to 400˚C)
± (1.0% + 3.6˚F)
± (1.0% + 2.0˚C)
Sensor must be thermocouple type.
Stated accuracy does not account for thermocouple accuracy
• “Lo” NCV light indicates
voltage <120V.
“Hi” NCV light indicates the
presences of voltage >120V.
NOTE: The worklight will turn
off during NCV tests.
/
