UEi ATTPC3 User Manual

9
WARNING
• Do not measure resistance
on a live circuit.
Range Resolution Accuracy Overload Protection
400Ω 100mΩ
± (1.0% +4 dgts)
600V RMS
4kΩ 1Ω
40kΩ 10Ω
400kΩ 100Ω
4MΩ 1kΩ
40MΩ 10kΩ ± (2.0% +4 dgts)
Hi-NCV-Lo
MFD
°F °C
µA
CAT Ill
600V 400A
MAX/MIN
HOLD
Hz / Duty
SELECT
TEMP
DISCONNECT
30V MAX
TESTLEADS
True RMS
DL389B
MAX
CATll1000V
CATIII600V
Hi-NCV-Lo
MFD
°F °C
µA
CAT Ill
600V 400A
MAX/MIN
HOLD
Hz / Duty
SELECT
TEMP
DISCONNECT
30V MAX
TESTLEADS
True RMS
DL389B
MAX
CATll1000V
CATIII600V
• Buzzer sounds at less
than 50Ω.
WARNING
• Do not measure resistance
on a live circuit.
Open Circuit Voltage Overload Protection
<0.44V 600V RMS
Threshold approx. <50Ω
• Default =
• Press x1 =
Resistance: < 40MΩ
Continuity
Ω
Features:
Features:
RANGE
