Ultima NEO User Manual

SPECIFICATIONS
Model: Ultima NEO
Channel Dual, isolated
TENS:
Intensity 0-100mA zero to peak at 500ohm load
Frequency 1-150 Hz
Pulse width 50-250μs in steps of 10μs
Waveform Symmetrical bi-phase rectangular,
Asymmetrical bi-phase rectangular,
Mono-phase rectangular
Treatment timer Continuous, 15, 30, 45, 60, 90min
EMS:
Intensity 0-100mA zero to peak at 500ohm load
Frequency 1-120 Hz
Pulse width 50-400μs, in steps of 50μs
Waveform Symmetrical Bi-Phasic rectangular,
Alternated Bi-Phasic rectangular
Ramp up time 0-8s in steps of 1s
Ramp down time 0-8s in steps of 1s
On time 1-60s in steps of 1s
Off time 0-60s in steps of 1s
Treatment timer Continuous, 10, 20, 30, 45, 60, 90min
Program M– When using ALTERNATIING Frequency
,
ensure that the “Ramp Up Time”, “On Time”, and “Ramp
Down Time” equals “Off Time”.
Ramp Up + On Time + Ramp Down = Off Time
- 19 -
