ELECTRODES PLACEMENT
Please study the body maps in this guide, which illustrate
placement of the electrodes depending on your symptoms.
Note: 1B =Channel 1 black / 1R =Channel 1 red
2B =Channel 2 black / 2R =Channel 2 red
Examples of electrodes placement for TENS:
0 & 1 – HANDS & FEET
These modes require the use of special electrode garments
not included. These program modes should only be used
under the direct care and supervision of your Professional
Healthcare Provider.
Note to Professional Healthcare Provider: Should you
choose to source electrode garments and prescribe these
treatment modes, please ensure that the garment selected
is designed to function in accordance with the following
instructions for use, and with the output specifications of
this device.
Using a single channel, connect one lead to the garment,
and connect the other lead to an electrode which is placed
on the lower arm or lower leg.
- 24 -
