I. UT208 only: Temperature Measurement (see figure 11)
The temperature measurement range: -40 ~1000
and -40 ~1832 .
To measure temperature measurement, connect the
Meter as follows:
Insert the red temperature probe into the V Hz
terminal and the black temperature probe into
the COM terminal.
Set the rotary switch to
. Press SELECT to
switch between
and measurement mode.
Place the temperature probe to the object being
measured.
The measured value shows on the display.
1.
2.
3.
Figure 11
Model UT207/208: OPERATING MANUAL
35
