UNI-T UT33D User Manual

Note
l When battery testing has been completed, disconnect the connection between
the testing leads and the circuit under test.
Measurement Operation (16)
H. The Model UT33D: Square Wave Output
To avoid damages to the Meter, do not allow output terminals (red test lead)
to reach higher than 10V.
Warning
To measure square wave output proceed as follows:
1. Set the rotary switch to OUT.
2. The square wave signal outputs between VΩmA and COM Terminals.
Note
l The frequency is approx. 50Hz.
l The output scope higher than 3Vpp when it is loaded 1MΩ.
28
Model UT33B/C/D: OPERATING MANUAL

UNI-T UT33D Specifications

General

Diode test	Yes
Product type	Digital multimeter
AC voltage range	200 - 500 V
DC current range	0.02 - 10 A
DC voltage range	0.2 - 500 V
Basic accuracy (DC current)	±(1%+2)
Basic accuracy (DC voltage)	±(0.5%+2)
Basic accuracy (resistance)	±(0.8%+2)
Dimensions (WxDxH)	73.5 x 35 x 130 mm
Battery voltage	9 V

Weight and Dimensions

Weight	156 g
