UNI-T UT71E User Manual

46
Model UT71A/B/C/D/E: OPERATING MANUAL
Note
The current of the object being measured must >
10A.
5A continuous measurement is allowed.
5A~10A, only 10 seconds continuous measurement
is allowed and the interval between each
measurement must be greater than 15 minutes.
When power measurement has been completed,
first switch off the power, then disconnect the
connection between the adaptor and the outlet.
l
l

UNI-T UT71E Specifications

General

Data hold	Yes
Product type	Digital multimeter
Frequency range	0.04 - 40000 kHz
AC current range	0.4 - 10 A
AC voltage range	4 - 1000 V
DC voltage range	0.4 - 1000 V
Capacitance range	40 - 40000 nF
Statistic function	Maximum, Minimum
Basic accuracy (frequency)	0.01%+8
Basic accuracy (DC current)	0.08%+8
Basic accuracy (DC voltage)	0.025%+5
Basic accuracy (resistance)	0.3%+8
Basic accuracy (capacitance)	1%+20
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	93 x 40 x 200 mm
Battery voltage	9 V

Weight and Dimensions

Weight	384 g
