▶ Administrator authentication
If you enter the administrator ID, the administrator
authentication is fulfilled along with the
authentication method of the administrator such as
card, face, or password.
The administrator authentication only appears when
the registered administrator exists. The
authentication is fulfilled only once when entering
the menu mode and you can access to all the menu
until you quit the main menu.
<Fig. 3.-2>
3.1.3. How to enter the menu without administrator authentication
It is how to enter the menu when the face authentication is impossible because the
administrator card registered in the terminal was lost or there is no administrator.
① Open the cover by removing the bracket at the backside of the terminal
② With the opened cover, connect the 5pin connector number 1 with 3, and 2 with 4 at
the bottom of the backside of the terminal.
<Fig. 3-3>
③ Click the icon at the basic window to enter the administrator authentication
window in <Fig. 3-2>, and fill the administrator ID as ‘0000’ (User ID length) and
click [ ] button, then you can enter the menu window.
▶ Be sure to remove the connection pin of the connector after modifying the setting
value.
