801 South Pine Street
Madera, California 93637
TEL: (800) 926-LIFT or (559) 662-3900
FAX: (559) 673-6184
Parts FAX: (559) 662-4785
107098-000
06-02
Local Distributor:
Safety Rules and Operating Instructions
Safety Rules and Operating Instructions
S
PECIFICATIONS
*
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Service Manual for complete parts and service information.
The TM12 meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1999
ITEM SPECIFICATION
Platform Size
29 in. x 41 in. (73,7 cm x 1,04 m) Inside Toeboards
Maximum Platform Capacity
500 lbs. (227 kg)
Maximum Number of Occupants
Two people
Height
Working Height 18 ft. (5,5 m)
Maximum Platform Height 12 ft. (3,66 m)
Minimum Platform Height 19 in. (48,3 cm)
Dimensions
Weight 1710 lbs. (776 kg)
Overall Width 30 in. (76 cm)
Overall Height 65 in. (165 cm)
Overall Length 53.5 in. (1,36 m)
Driveable Height
12 ft. (3,66 m)
Drive Speed
Platform Lowered 2.27 mph (3,65 km/h)
Platform Raised .62 mph (0,99 km/h)
Energy Source
24V battery pack
Four 220 ampere hour, 6 Volt batteries, min. wt. 62 lbs. (28,12 kg) each
4 HP DC electric motor
System Voltage
24 VDC
Battery Charger
20 AMP, 110/220 VAC
Hydraulic Tank Capacity
1.9 gal (7,2 L)
Maximum Hydraulic System
Pressure
3000 psi (207 bar)
Hydraulic Fluid
Above 32° F [0° C]
Below 32° F [0° C]
Below 0° F [-17° C]
ISO #46
ISO #32
ISO #15
Lift System
One Single Stage Lift Cylinder
Drive Control
Proportional
Control System
Proportional Control Handle with Interlock, Selector Switch,
Red Mushroom Emergency Stop Switches
Drive System
Dual Front Wheel Hydraulic Motors
Tires
12 in. (30,5 cm) diameter solid rubber, Non-marking
Parking Brakes
Dual, Spring Applied, Hydraulic Release
Turning Radius
14.5 in. (37 cm) Inside
Maximum Gradeability
25% (14º)
Wheel Base
38.5 in. (97,8 cm)
Guardrails
45 in. (1,14 m)
Toeboard
6 in. (152 mm)
