V2 FORTECO User Manual

ENGLISH
31
TECHNICAL SPECIFICATIONS
FORTECO
1200-230V
FORTECO
1800-230V
FORTECO
2200-230V
Gate maximum weight 1200 Kg 1800 Kg 2200 Kg
Power supply 230VAC / 50Hz 230VAC / 50Hz 230VAC / 50Hz
Maximum power 600 W 650 W 800 W
Idling current 1.9 A 1,4 A 2 A
Full load current 3 A 3,2 A 4 A
Running capacitor 12 µF 18 µF 18 µF
Start off capacitor 12 µF 14 µF 14 µF
Gate maximum speed 0.16 m/s 0.16 m/s 0.16 m/s
Maximum thrust 900 N 1300 N 1550 N
Duty cicle (ambient temperature +55°C) 35% 35% 35%
Pinion M4 - Z18 M4 - Z18 M6 - Z12
Operation temperature -20°C ÷ +55°C -20°C ÷ +55°C -20°C ÷ +55°C
Weight 16 Kg 18 Kg 18 Kg
Protection IP44 IP44 IP44
Maximum load on 24 VACattachments 10W 10W 10W
Protection fuses F1 = 10A F1 = 10A F1 = 10A

V2 FORTECO Specifications

General

Brand	V2
Model	FORTECO
Category	Gate Opener
Language	English
