Appendix
Appendix
1. LED Indicators
The EzSensor Hardware Controller has two LED indicators that show its functional status.
The location of the LED lights is shown in the following illustration and described in Table 3.
LED 1
LED 2
< Table 3. Description of LED Indicators >
Operational State
LED State
LED 1 LED 2
Functional Status
Confirmation
Initial State
Standby
Trigger (X-ray On)
Data Transmission
with USB cable
Image acquisition
Green
Green
Orange
Green Orange
Green
Off
Green
Green
Off
37
USB Connection
Board On
X-ray On and Sensor Trigger On
Confirm data transmission
with sensor board
Completion of data transmission
with PC-board
