Vax Platinum PowerMax ECB1SPV1 User Manual

Using your machine
Filling the water/solution tank and cleaning modes
Press the clean water/
solution tank release
button, pull and lift to
remove the tank.
Twist the water/solution
tank cap anti-clockwise
and remove.
Pour the required amount
of carpet cleaning solution
into the tank. Tighten the
cap before returning the
tank to the washer.
Fill the clean water tank
with warm water (max
40°C). Fill to max ll line
for a Deep Clean, and ll to
the Quick Clean ll line for
a quick surface clean.
Tilt and line up the front of
the tank to the washer and
push the tank back until it
clicks into place.
Turn the wash/rinse dial
to ‘wash’. The SpinScrub
brushes and brushbar
deep clean your carpets
with water and solution
removing dirt and stains.
TIP
This machine has an auto mix tank so any solution
not used can be poured back into the bottle.
Plug into the mains,
press the On/O button
to switch on.
Choose the cleaning
mode by turning the dial
on the base.
NOTE: Carpets should be dry vacuumed thoroughly before washing. For heavily soiled areas, it may be necessary
to repeat the cleaning process. Make criss-crossing strokes across the original pattern and overlap with each pass.
Quick Clean Mode:
Best for a quick, surface
clean - carpets dry in
less than an hour.
Deep Clean Mode:
Best overall results for
a thorough, deep clean.

Vax Platinum PowerMax ECB1SPV1 Specifications

General

Style	Upright
Color	-
Total Power	1200 W
Suction Power	-
Dust Bin Capacity	2.9 L
Power Controls	-
Operating Radius	-
Cord Length	9 m
Hose Length	4.6 m
Automatic Cord Rewind	-
Exhaust Filter	-
Motor Protection Filter	-
Park system	-
?leaning Area	-
Noise Level	-
Cleaning Modes	Spot
Features	Telescopic suction wand
Brushes and Accessories	Dusting brush with synthetic bristles
Power Consumption	-
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	410 mm
Height	1100 mm
Width	340 mm
Net Weight	9.6 kg
