1
2 3
H
ose attachments
Put the cleaner in its upright
position. Turn the brush switch and
power switch to the off position.
Remove the hose from its stored
position on the back of the cleaner.
Lift the hose attachment cover
located on the top of the dirty water
tank.
Insert the end of the hose into the
tool opening and twist clockwise
until it locks into place.
4
5 6
Attach the water supply connector
into the hose water supply port at
the side of the machine. Press
firmly until it locks into place.
Move the floor/tools selector to the
tools (upward) position.
To wash upholstery, be sure that
the brush switch is OFF and that
the power and soap switches are
turned ON.
Note: Do not allow upholstery to
become too wet.
16
17
V-027M User Guide 7/9/06 15:00 Page 8
