POS App Guide DIM Installation Examples
31
Tokheim Dispensing Systems
• Tokheim Vision 100/200, MEMS IV, or MEMSV controllers
• CFN2 controllers
• ANDI or Columbus controllers
• Schlumberger MicroMax XPIC/DHC
• 67/A - 98 or 67/B controllers
TLS CONSOLE SOFTWARE REQUIREMENTS
TLS-350R with BIR Software Requirements
• System software Version 17 (or higher)
TLS-450/TLS-450PLUS
• Not supported
VEEDER-ROOT HARDWARE REQUIREMENTS
Specific DIMS and installation kits are listed in Table 2 on page 7.
TOKHEIM DHC REQUIREMENTS
• SCS 1200 default setting for serial port J2
• SCS 9600 default setting for serial port J4
• Version 5, rev 6, dated 11/1989 (or later)
The Tokheim DHC itself can be:
• Standalone (and used with a third party POS). or
• An internal component of a Tokheim Vision 100 Vision 200, MEMS IV, or MEMS V Console
SPECIFIC LIMITATIONS
Only Tokheim dispensers are supported. Tokheim electronic blenders are supported. The dispensers may feature
electronic card readers. Mechanical blenders that blend fuel prior to the metering process are not supported (not a
restriction for ISD only applications).
OTHER POS CONSOLES
Other POS consoles that interface to the Tokheim DHC may also be supported. Contact Veeder-Root for
assistance.
INSTALLATION NOTES
Connection examples for Tokheim dispenser systems are shown in Figure 12 - Figure 14 below.
