Videx 6286 User Manual

66251130-EN - V1.4 - 30/06/16
4
6200 Series
Art.6286 - Installation instructions
SIGNALS ON CONNECTION TERMINALS
BUS1 Bus input
BUS2 Bus input
GND Ground
+12VM +12Vdc power supply input for version with memory board option
GND Ground
+VAUX Auxiliary power supply input (to be used when the switch 4 of SW3 is set to ON)
C
Dry contact Max 50Vdc @ 100mA. Internally linked to NO when the
button is pressed. Max 35Vdc, 10mA
NO
Dry contact Max 50Vdc @ 100mA. Internally linked to C when the
button is pressed. Max 35Vdc, 10mA
DOL Auxiliary LED power supply input (ground)
+DOL Auxiliary LED power supply input (+12Vdc)
AL-LB_GND Ground output for use in combination with “AL” & “LB” active low inputs
LB Local bell input (active low)
AL Alarm input (not implemented yet)
SPECIFICATION
Housing/Mounting: 6200 Series Videophones / surface mount
Push buttons: Yes, 4
Programming: Yes, carried out by the buttons and the dip-switches located on the rear of the videophone
Controls: Call tone volume, brightness and hue
Power Supply: Supplied by the BUS line
Power consumption: Stand-by: 0.2mA
Operating: 200mA
Working Temperature: -10 +50 °C
Art.6286 3.5" colour display videophone
CUSTOMER SUPPORTMANUFACTURER
All Countries:
VIDEX ELECTRONICS S.P.A.
www.videx.it - technical@videx.it
Tel: +39 0734-631669 - Fax: +39 0734-632475
VIDEX ELECTRONICS S.P.A.
Via del Lavoro, 1 - 63846 Monte Giberto (FM) Italy
Tel (+39) 0734 631669 - Fax (+39) 0734 632475
www.videx.it - info@videx.it
UK Customers:
VIDEX SECURITY LTD
www.videx-security.com
Tech Line: 0191 224 3174 - Fax: 0191 224 1559
The product is CE marked demonstrating its conformity and is for distribution
within all member states of the EU with no restrictions. This product follows
the provisions of the European Directives 2014/30/EU (EMC); 2014/35/EU
(LVD); 2011/65/EU (RoHS): CE marking 93/68/EEC.
