Set-up
14
Enclosure Panel Installation
All the parts required for mounting the
enclosure panels are supplied in the
carton containing the insulation.
1. Push the insulation blanket (with black
side facing outwards) under the boiler
andwrapthemataroundtheboiler
shell.
2. Allow the two ends to overlap, and
fasten with three spring-clips.
3. Insert the front retaining brackets and
twist the tabs.
4. Insert the rear retaining brackets and
twist the tabs.
5167 404 v1.9
IMPORTANT
