Fault Code Register
CAUTION!
Read the
safety precautions for maintenance and service in the Safety Information chapter before starting work.
When a malfunction is discovered the helmsman is warned by a sound alarm and at the same time a message
is shown in the display.
This chapter gives a more detailed description of the messages together with suggested actions to take.
Message
If a malfunction is discovered a message is shown on
the display.
The message is presented in the list below
together with a description of how the system might be
affected and suggested actions to take.
Alarm Display (optional)
If a lamp in the alarm monitor flashes a malfunction is
detected.
1 Is the orange “water in fuel” lamp lit there is to much
water in the water separator on the fuel pre-filter.
2 Is the charging lamp lit the alternator has stopped
charging.
3 Is the coolant temperature lamp lit the coolant tem-
perature is to high.
4 Is the orange coolant level lamp lit during operation
the coolant level is to low.
5 Is the orange oil level lamp lit during operation the
engine oil level is to low.
6 Is the red warning lamp lit during operation a seri-
ous malfunction has been discovered.
Is the orange warning lamp lit during operation a
malfunction has been discovered.
7 Is the red oil pressure lamp lit during operation the
engine oil pressure is to low.
47705796 05-2014 © AB VOLVO PENTA 71
