Technical Data: TD/TAD520, TAD530/531/532
37
Group 20
Type: .................................................................... Wet, replaceable
Number of seals per liner: ..................................... 2
Bore: ..................................................................... 108
+0.02
mm (4.252"
+0.0008"
)
Max bore wear: ..................................................... 108.1 mm (4.256")
Height sealing surface (A): .................................... 9
-0.02
mm (0.3543"
-0.0008"
)
Liner collar seating depth in block: ........................ 8.92
+0.03
mm (0,3512"
+0.0012"
)
Projection of liner above block surface: ................. 0.03 – 0.08 mm (0.0012" – 0.0031")
A
Cylinder liners
TD520GE/TAD520GE
TD520VE/TAD520VE
TAD530/531/532GE
Engine block
Cylinder head
Type: ........................................ Common cylinder head
Max surface unevenness: ......... 0.085 mm (0.00335")
Cylinder head bolts
Thread size: .............................. M 14
Quantity and length: .................. 18 x 141 mm ( 18 x 5.55")
1)
See engine plate for specifications.
2)
Weight according to DIN 70020-A
3)
Extra weight TAD520GE SAE 2 (1800 rpm) 36 kg (80 lb)
4)
Including clutch and frame
General
Type designation ..............................................
Direction of rotation (seen from flywheel)
No. of cylinders ................................................
Cylinder bore mm (inch) ...................................
Stroke mm (inch) .............................................
Cylinder volume liter (inch
3
) .............................
No. of valves....................................................
Compression ratio:
EPA1 ............................................................
EPA2 ............................................................
EU2 ..............................................................
Injection sequence ...........................................
Engine power:
At 1500 rpm kW (hp) .....................................
At 1800 rpm kW (hp) .....................................
Torque Nm (lbf.ft) .............................................
At engine speed rpm .....................................
Torque Nm (lbf.ft) .............................................
At engine speed rpm .....................................
Low idle rpm .....................................................
Highest full load speed rpm ..............................
Weight, dry (lb) .................................................
Gross weight, dry (lb)
TAD531GE
Anti- clockwise
4
108 (4.25”)
130 (5.12”)
4.76 (290)
8
18.0:1
1-3-4-2
102 (139)
1)
110 (150)
1)
649 (479)
1500
584 (430)
1800
800 – 950
1500/1800
1)
575 (1268)
2,3)
606 (1336)
2,3)
TAD530GE
Anti- clockwise
4
108 (4.25”)
130 (5.12”)
4.76 (290)
8
18.0:1
1-3-4-2
89 (139)
1)
95 (150)
1)
567 (479)
1500
504 (430)
1800
800 – 950
1500/1800
1)
575 (1268)
2,3)
606 (1336)
2,3)
TAD532GE
Anti- clockwise
4
108 (4.25”)
130 (5.12”)
4.76 (290)
8
18.0:1
1-3-4-2
129 (139)
1)
136 (150)
1)
821 (479)
1500
722 (430)
1800
800 – 950
1500/1800
1)
575 (1268)
2,3)
606 (1336)
2,3)
Replacable, wet
