Service Information
Document Title: Function Group: Information Type: Date:
Brake calliper removed,
reconditioning
511 Service Information 2014/8/21
Profile:
ART, A30D [GB]
Brake calliper removed, reconditioning
Op nbr 511-081
To remove brake calipers, see .
464 Spindle, replacing one side
WARNING
Brake fluid can cause skin irritation. Use protective gloves.
Dismantling
1. Fit the brake pad retainers. Fit a wooden block 300x75x20 mm (12x3x0.8 in) between the brake pad retainers. Press
out the pistons with compressed air.
Figure 1
2. Remove the brake pistons (4 pcs.).
