Description of the Machine
8.4 Components
34
Operator’s manual | AS | 5100056974 | 06/2020 | [us]
8.4 Components
1
2
3
4
5
6
7
8
AS30e
1 Rechargeable battery
2 Guide bracket
3 Vibration absorber
4 Drive motor
5 Crankcase
6 Ramming system
7 Ramming shoe
8 Type label
1
2
4
5
6
7
8
3
AS50e/AS60e
1 Rechargeable battery
2 Guide bracket
3 Vibration absorber
4 Drive motor
5 Crankcase
6 Ramming system
7 Ramming shoe
8 Type label
8.5 Control elements
1
4
5
2
3
AS30e
1 Guide bracket
2 Start and safety level
3 Lock
4 Handle
5 Central suspension
