8 Storage
20 100_0201_tr_0004.fm
7.1.2 Lifting and lashing down the machine
1. To lift the motor, hang suitable tackle at the central lifting point.
2. Carefully load machine into or onto a stable means of transport.
3. Move the machine forward onto the roller kit.
4. After loading the machine, lash down the machine to prevent it from rolling off, slipping, or tipping
over. Attach and tension the tension belt over the vibratory rammer.
8Storage
If the machine will not be operated for longer periods of time, e.g. during the winter months, carry out the
following activities:
Do not store the machine outdoors.
Store dry and free of dust.
Empty the fuel system.
NOTICE
Appoint a specialist flagman for a safe lifting operation.
Item Designation Item Designation
1 Central lifting point 2 Roller kit
