13 Technical data
36 100_0201_td_0004.fm
13.3 BS50-2plus
Designation Unit BS50-2plus
11"
BS50-2plus
11" US
BS50-2plus
11" ha US
BS50-2plus
6" (24mm)
Item number 5100030596 5100030594 5100030595 5100030597
Percussion rate rpm 687
Impact force kN 16
Travel speed m/min 9,5 7,9
Length mm 673
Width mm 343
Height mm 940
Length (ramming shoe) mm 340
Width (ramming shoe) mm 280 165
Weight kg 59 56
Operating power kW 1,7
Operating speed* rpm 4.250
Standard ISO 3046-1
Operating temperature range °C -10 – +40
Sound pressure level L
pA
dB(A) 92
Sound power level L
WA
measured
guaranteed
dB(A)
dB(A)
107
108
Vibration total value a
hv
m/s
2
9,8 5,4
Uncertainty of measurement
of the vibration total value a
hv
m/s
2
1,5
Oil specification SAE 10W-40
Oil quantity l 0,7
*
Depending on the operating parameters, material properties and environmental impacts.
