5
English
Material Container Setup
1. Remove the material container from the pump housing
by turning the pump housing ring counterclockwise.
7. Twist the pump housing ring to thread the container onto
the pump housing. Plug in the unit.
3. Fill the container with the material to be used.
5. Insert the suction tube into the intake opening.
2. Remove the suction tube.
4. Place a few drops of household oil down the intake (a)
and return openings (b) in the pump housing.
6. Line up the tab (c) on the pump housing with the notch
(d) on the material container.
