Remote Suction Set Setup (optional)
1. Remove the material container from the pump housing
by turning the pump housing ring counterclockwise.
7. Submerge the suction tube assembly into the material
container and attach the container clip (l) to the side
to hold it securely. Make certain the return line (m) is
inside the container.
3. Place a few drops of household oil down the intake (a)
and return (b) openings in the pump housing.
5. Push the remote suction hose onto the intake and return
ports of the dual hose tting. The larger hose (f) goes
onto the intake port (g).
2. Remove the suction tube.
4. Push the dual hose
tting (c) into the intake
and return openings
on the bottom of the
housing. The tting
with the ridge (d) goes
into the return opening.
Twist the pump housing
ring (e) clockwise to
tighten the dual hose
tting into place.
6. Slide the intake hose [(h), the larger hose] through
the container clip (i). You may need to pull the hoses
slightly apart.
Push the intake hose onto
the suction tube so that it
is ush with the ridge (j).
Make certain that the intake
lter (k) is in place on the
suction tube.
(m)
(l)
(g)
(f)
(d)
(c)
(e)
(a)
(b)
(i)
(h)
(j)
(k)
