Thermo Call TC3

Connection

Connector assignment of GSM module

*: The connection may vary depending on the installed 2nd heater.

Information on the integration is contained in the respective heater installation instructions.

Socket Function Remarks

1 12 - 24 V (+30)

2 Earth = 0

3 Output of parking heater only for Thermo Top E/C

4 additional analogue output, 12-24 V positive * for 2nd installed heater with analogue con-

trol

5 Earth output for summer function (fan only) only for Thermo Top E/C

6 W bus communication with parking heater or digital timer/Telestart only for Thermo Top Evo

7 not in use (optional Input 1 for alarm system) +12 V

8 Input 2 (for digital timer/Telestart) only for Thermo Top E/C

9 Earth for push button (blue wire)

10 On/Off for push button (green wire)

11 Output for LED in push button (red wire)

12 not in use
