Webasto Thermo Top Z/C - D User Manual

Electrical system
32
12 Circuit Diagrams
Legend for wiring diagrams see fig. 18:
System wiring diagram for Thermo Top Z/E/C and Z/C, 12 V.
The line cross-sections specified in the system wiring diagram
apply for line lengths < 4.5 m.
Tabelle 1: Cable colours
bl blue
br brown
ge yellow
gn green
gr grey
or orange
rt red
sw black
vi violet
ws white
