15.3. Technical Data for Thermo Top Z/E/C
Heater O
peration Thermo Top C - B Thermo Top Z - D
Thermo Top C - D
Thermo Top E - B Thermo Top E - D
EC approval mark E1 10R - 03 1232
E1 122R - 00 0002
E1 122R - 00 0003
Model Water heater with evaporator-type burner
Fuel Petrol
EN 228
DIN 51625
Diesel/PME
EN 590
DIN EN 14214
Petrol
EN 228
DIN 51625
Diesel
EN 590
Heat flow [kW] Full load
Part load
5.2
2.5
4.2
2.5
Fuel consumption
+/- 10 % [l/h]
Full load
Part load
0.70
0.34
0.61
0.30
0.56
0.34
0.49
0.30
Nominal power consumption (without
circulation pump and vehicle fan)
+/- 10% [W]
Full load
Part load
28
18
23
18
Nominal voltage [V] 12
Operating voltage range [V] 10.5 to 15
Bias current consumption [mA] < 1.0
Perm. ambient temperature [°C]
Heater: - Operation
- Storage
-40 to +60
-40 to +120
Perm. operating pressure (heat exchanger)
[bar]
0.4 to 2.5
Capacity of the heat exchanger [l] 0.15
Minimum quantity of coolant circuit [l] 4.0 3.0
Minimum flow rate for heater
[l/h]
250
CO
2
in exhaust gas (perm. function range)
[vol. %]
8 to 12.0
Dimensions of heater without attached parts
Also see fig. 2. [mm]
(Tolerance ± 3 mm)
Length: 214
Width: 106
Height: 168
Weight [kg] 2.9
