24
Bonnet
The Bonnet functions as a cover and guard for the Waste Port as the Globe rotates.
The Bonnet also provides a mount location for the Night Light, wires, and electrical
terminals that provide a low and safe 5VDC to the Night Light LED. The Globe will not
rotate without the Bonnet installed (see Control Panel - Indicator Lights Yellow Light
Flashing, page 20). See page 30-31 for assembly instructions.
Key
The Key is located at the back of the Globe. Position the Key by snapping it into the
pocket in the Base.
Night Light
Underside of Bonnet
Key
Bonnet
To Next Page
