11
Operations
Technical Specifications
ITEM DIMENSION/CAPACITY
Construction Steel chassis with rotationally molded polyethylene tanks
Vacuum Motor
Three stage, bypass, 1.5 hp (1,119 watts), 100 cfm (2.8m³/min), 120" (3050 mm)
waterlift
Solution Pump
100 psi (7 bar) - Restorative
50 psi (3.5 bar) - Interim
Brush Motor 1/2 hp (604 watts) AC with circuit breaker protection
Brushes 2 x 16" (406 mm), ABS core, Perform Alert™ bristle spiral pattern
Cleaning Path 16" (40.6 cm)
Flow Rate
Interim - 0.09 gpm ( 0.37 lpm)
Restorative - 1.0 gpm (37.8 lpm)
Solution Spray
Interim - One quick-disconnect jet
Restorative - One quick-disconnect jet
Solution Tanks 10 gallons ( 37.8 l)
Recovery Tank 10 gallons (37.8 l)
Vacuum Shoe 18" (458 mm) wide, cast aluminum
Wheels 10" (254 mm) non-marking rubber
Power Cable 50' (15 m) detachable
Weight 166 lbs (75.3 kg) with cord
86302100 CLIPPER DUO
