Windsor CS20 User Manual

10
Operations
Technical Specifications
ITEM DIMENSION/CAPACITY
Nominal Power-Disk 1080 W
Nominal Power-Orbital 936 W
Nominal Power-Cylindrical 1512 W
Rated Voltage 36 Volts DC
Rated Amperage -Disk 30 amps
Rated Amperage -Orbital 26 amps
Rated Amperage -Cylindrical 42 amps
Batteries 3 X12 Volt 130 AH @ 20 hr. rate
Battery Compartment Dimensions 20-1/2 in. x 13 in. x 10 in. tall (330mm x 521mm x 254mm)
Scrub Brush Motor - Disk Machine 1 x .28 HP (209 W)
Scrub Brush Motor - Orbital Machine 1 x .5 HP (373 W)
Scrub Brush Motor - Cylindrical Machine 1 x .8 HP (600 W)
Vacuum Motor .63 HP (470 W)
Maximum flow rate of vacuum motor 72 cfm (33.98 liters per second)
Maximum suction of vacuum motor 47.3 inches of water (11.7 kPa)
Propelling Motor .38 HP (280 W)
Mass (GVW) 827 lbs (375 kg)
Weight empty without batteries - Disk 209 lbs (96 kg)
Weight empty without batteries - Orbital 271 lbs (123 kg)
Weight empty without batteries - Cylindrical 255 lbs (116 kg)
Solution Control Gravity, 1/3 GPM average
Solution capacity 10 gal (38 L)
Recovery capacity 10 gal (38 L)
Scrub brush diameter - Disk 20 inch (508 mm)
Scrub brush length - Cylindrical 22 inch (559 mm)
Scrub brush pressure - Disk / Orbital 50 lbs (222N)
Scrub brush pressure - Cylindrical 46 lbs (21 kg)
Scrub brush speed - Disk 180 rpm
Scrub brush speed - Cylindrical 1500 rpm
Tires 8 in. (203mm) drive, 6 in. (156mm) rear, polyurethane
Maximum Speed 2.4 mph (3.7 kph)
Brake Electrical parking brake,sets automatically whenever operator stops.
Minimum aisle u-turn width 51in. (1295 mm)
Maximum rated climb and descent angle 10% (6 degrees)
Vibration, hands - Disk 1.6 m/s²
Vibration, feet - Disk 0.54 m/s²
Uncertainty - Disk 0.5 m/s²
Sound pressure level - Disk 68.0 dBA
Sound power level - Disk 81.1 dBA
Uncertainty - Disk 3.0 dBA
Vibration, hands - Cylindrical 1.5 m/s²
Vibration, feet - Cylindrical 0.9 m/s²
Uncertainty - Cylindrical 0.5 m/s²
Sound pressure level - Cylindrical 71.5 dBA
Sound pressure level - Cylindrical 84.7 dBA
Uncertainty - Cylindrical 3.0 dBA
86398220 Operators Manual - Chariot-2 iScrub 20
