8
Operations
Technical Specifications
ITEM DIMENSION/CAPACITY
Nominal Power 1548 W
Rated Voltage 36 Volts DC
Rated Amperage 43 amps
Batteries 3 X12 Volt 195-215 AH @ 20 hr. rate
Battery Compartment Dimensions 21 in. x 16 in. x 17 in. tall (533mm x 406mm x 432mm)
Propelling Motor 0.75 HP (560 W)
Brush Motor 0.5 HP (373 W)
Side Broom Motor 0.06 HP ( 47W)
Bag Capacity (HEPA) 1019 in³ (16.7 L)
Hopper Capacity 54.9in³ (0.93 Liters)
Brushes Two 28 in. (71 cm) by 4 in. (10 cm) diameter
Side Broom 13 in (33 cm)
Brush Speed 1125 RPM
Side Broom Speed 90 RPM
Vacuum Motor 0.75 HP (560 W)
Maximum flow rate of vacuum motor 200 cfm (95 liters per second)
Suction of vacuum motor with new HEPA bag. 4.8 inches of water (1.19 kPa)
Vacuum bag full shut off 14-16 inches of water (3.5-4.0 kPa)
Maximim suction of vacuum motor 23-26 inches of water (5.7-6.5 kPa)
Weight (GVW) Gross Weight Batteries 1035 lbs (470 kg)
Weight Empty Without Batteries 467 lbs (212 kg)
Tires 10 in. (254mm) Solid Gray non-marking
Foundation Pressure 79 psi (544 kPa)
Maximum Speed 3.5 miles/hour (5.7 Km/hour)
Frame Construction Powder coated steel
Brake
Electrical parking brake, sets automatically whenever
operator steps off platform or engages emergency stop.
Minimum Aisle U-Turn Width 61 in. (1550 mm)
Maximum Rated Climb And Descent Angle 10.0 degrees
Sound Pressure level at operator’s ear (IEC 60704-1) 69.7 dBA Uncertainty 3.0 dBA
Sound Power (IEC 60704-1) 84.3 dBA Uncertainty 3.0 dBA
Vibration Hands (ISO 5349) 1.32 m/sec² Uncertainty 0.5 m/sec²
Vibration Feet (ISO 5349) 0.52 m/sec² Uncertainty 0.5 m/sec²
86347810 Chariot iVacuum 34
