11
Operations
Technical Specifications
Special Notes:
The sound pressure level at the operator's ear was measured to be 74dBA . This was a nearfield, broadband
measurement taken on a carpeted floor. This appliance contains no possible source of impact noise. The
instantaneous sound pressure level is below 63 Pa. The weighted root mean square acceleration at the
operator's arms was measured to be below 2.5m/s2. This was a tri-axial, third-octave-band measurement made
during normal operation on a composite tile floor. The measurement and related calculations were made in
accordance with ANSI S3.34-1986.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
ITEM DIMENSION/CAPACITY
Rated Amperage (120V) 15 AMPS
Rated Amperage (230V) 7.5 AMPS
Brush Motor 0.5 HP (373 W)
Bag Capacity 792 in³ (13 L)
Brush Two 25.5 in. (647mm) by 4 in. (10 mm) diameter
Brush Speed (120 V) 1550 RPM
Brush Speed (230 V) 1350 RPM
Maximum flow rate of machine 129 cfm (61 L/sec)
Maximum suction of machine 20 inches of water ( 4.97 kPa)
Weight Empty 151 lbs (68 kg)
Tires 9.75 in. (247mm) non-marking
Frame Construction Powder coated steel
ITEM MAXIMUM STORAGE
Height 44 inches (1120 mm) 21 inches (530 mm)
Length 51.5inches (1310 mm) 33 inches (840 mm)
Width 30.5 inches (770 mm) 30.5 inches (770 mm)
