16
Maintenance
Components
1.
Primary Drive Belt
2.
Brush Motor
Assembly
3.
Belt G
uard
4.
Brush Deck
Assembly
5.
V
acuum Hose
6.
Hose Clamp
7.
Brush Deck Mounting Bolts
8.
Drive Housing Cover Plate
9.
Secondar
y T
iming Belt
10.
Drive Housing
1
1.
Belt T
ensioning Nut
12.
Belt T
ensioning Bracket
13.
Retaining Clips
86400820 Operators M
anual - NuW
ave
1
2
3
4
5
6
7
8
9
10
11
12
13
15
17
