Operation
The TRAV’LER Interface offers a simple one button operation that is also protected from accidental searches by a
careful delay. Simply pressing the [Power] button will not start a search.
To start a search:
Press and Hold [Power] for two seconds or until the TRAV’LER interface displays
“POWER ON”.
Now the power is ON, the button may be released.
Once the power is on, the TRAV’LER Interface will try to determine the type of dish that it is working with. The
TRAV’LER Interface will display the type of satellite dish on the top line and the action it is taking on the bottom.
See below.
The TRAV’LER antenna will enter the search mode as part of its normal operation. The rst part of the search is
for the TRAV’LER to nd its “Home” position. Once it nds it home position, it will begin to look for a satellite.
When the TRAV’LER antenna nds a satellite, it will ne tune or “Peak” on the signal and determine which of the
satellites it has found. Once the TRAV’LER knows which satellite it has found, it can move directly to the correct
satellite(s).
The TRAV’LER antenna in its automatic search mode will lock onto two dfferent satellites. As it nishes its search,
the TRAV’LER will display an “ * ” for each of the satellites it found. See below.
WINEGARD COMPANY
POWER ON
CONNECTING
TO ANTENNA
LG SHAW DIRECT
READY MULTI-SAT
3
LG SHAW DIRECT
*111 *107
Now you are ready to watch TV.
OPERATION
LG SHAW DIRECT
WAITING FOR GPS
Many times, the
TRAV’LER will acquire
GPS fast enough that
this screen is not seen.
