Connecting the supply hose
The hose may not be shortened or damaged.
Old existing hoses may not be re-used.
Do not bend the hose when laying it.
The supply hose and dirt trap are located in the machine.
INFO The dirt trap prevents particles from the water supply line entering the machine
thus preventing extraneous rust on the cutlery and in the machine.
Connect the supply hose to the machine.
Connect the dirt trap to the on-site water supply.
Connect the supply hose to the dirt trap.
Open the water supply and test whether the connections are tight.
Waste water connection
Connect the central water drain (A) to the drainage system in the building. The drain
pipe in the building should have a diameter of at least 50 mm and a sufficient slope
(min. 3°).
The waste water connection in the building must be located at a max. height of 100 mm
above the finished floor level. Alternatively, the waste water can be channeled into a
floor drain.
Install an odour trap into the drain pipe in the building.
26 Electrical connection
Danger to life. Live components.
The machine and the relevant additional devices must be connected by an
electrical company authorised by the relevant electricity supplier as per
the locally applicable standards and regulations.
When performing installation and maintenance work, unplug the machine
from the power network. Check that there is no voltage.
IMPORTANT Observe the connection diagram for detailed information.
The electrical safety of this machine is guaranteed only if it is connected to a correctly
installed protective circuit. It is very important that this basic safety requirement is test-
ed and in case of doubt the house installation is checked by a qualified electrician.
The circuit diagram must be observed.
The machine may only be operated at the voltages and frequencies specified on the
rating plate.
A mains disconnector with all-pole separation from the network must be installed. The
mains disconnector switch must have a contact opening width of at least 3 mm, and
must also be lockable in the neutral position. The installation site must be near the ma-
chine and easily accessible.
The electrical connection must be secured as a separately fused circuit with slow fuses
or circuit breakers. The protection depends on the total power consumption of the ma-
chine. The total connected load is specified on the rating plate of the machine.
We recommend to install a class B all-current sensitive residual current circuit breaker
with a release current of 30 mA (DIN VDE 0664)n the electrical supply line.
