4 89005779
4 Description of the machine
4.1 Operating panel
The operating panel is situated in the upper part of the machine.
1 On/Off switch
2 Tank drainage / self-cleaning
3 Control lamp for fault
4 Control lamp for lack of detergent or rinse aid (optional)
5 Control lamp for lack of salt or external water treatment exhausted
6 Programme button normal programme
7 Temperature display – Boiler
8 Temperature display – Tank
9 Function button – activates the special programmes (10-13)
10 Short programme
11 Reduced rinse temperature (optional)
12 Not allocated
13 Intensive programme
14 Button area for special programmes
DOS
12345 6 78 91011 12
14
13
