1. TRIGGER SWITCH
2. AUXILIARY HANDLE
3. HANDLE ROTATION LOCKING MECHANISM
4. HEIGHT ADJUSTMENT LOCKING MECHANISM
5. TELESCOPE TUBE
6. CUTTING HEAD ADJUSTMENT BUTTON
7. MOTOR HOUSING
8. FLOWER GUARD
9. CUTTING HEAD ASSEMBLY
10. SAFETY GUARD
11. CABLE STRAIN RELIEF ARM
12. LINE CUTTER (See Fig. B)
13. LINE FEED BUTTON (See Fig. K)
14. CUTTING HEAD COVER (See Fig. L)
15. CAP RELEASE LATCH (See Fig. L)
16. SPOOL (See Fig. L)
17. CUTTING HEAD (See Fig. L)
18. EYELET (See Fig. L)
Not all the accessories illustrated or described are included in standard delivery.
