Action Figure
ASSEMBLY
Assembling the Safety Guard See Fig. AI & A2
Mounting the Edger Wheel See Fig. B
Installing and Removing the Battery Pack See Fig. C
Charging the battery pack More details can be found in the charger’s m
anual
WARNING The charger and battery pack are specially designed
to work together so do not attempt to use any other devices. Never inse
rt or allow metallic objects into your charger or battery pack
connections because of an electrical failure and hazard will occur.
See Fig. D
Operation
Safety ON/OFF Switch See Fig. E
Trimming
Adjusting the Shaft See Fig. F
Adjusting the trimmer Head See Fig. GI, G2
Adjusting the Auxiliary handle See Fig. H
Trimming See Fig. 11
Using the Flower Guard See Fig. 12
Edging
Changing the tool into the Edging mode See Fig. J1, J2
Edging See Fig. K
Manually feeding the line See Fig. L
Replacing the trimmer spool See Fig. MI, M2,M3
Manually winding the line See Fig. N1, N2, N3, N4
OPERATION INSTRUCTIONS
1. Automatic line feed system
When initially switching on the trimmer, a small length of the line is fed out. Each time the tool is started from rest it
will advance about 0.25 inches of trimmer line.
A ‘clattering’ noise will be heard when the lines hit the Line Cutter. DO NOT BE ALARMED. This is quite normal.
After about 5 seconds the line will be cut to the correct length and the noise will reduce as the motor gains full
speed. If the noise of the line being cut can’t be heard, more lines will need to be fed out. To feed more line, it is
first necessary to allow the trimmer to stop completely; it must come to a complete rest, then restart, allowing the
motor to reach full speed. Repeat above until you hear the line hitting against the Line Cutter.
2. Manually feeding the line (See Fig. L)
Turn off the trimmer and remove the battery. If required, the line can be fed out manually. To operate, press and
release the manual Line Feed Button, while gently pulling out the line until it is long enough to reach the Line
Cutter. If the line extends past the Line Cutter, too much line has been fed out. If too much line is fed out, remove
the Spool Cap and turn Spool counter-clockwise until the line is at the desired length.
