SSeeccoonndd BBiiaass TTrraannssffeerr RRoolllleerr
RReeppllaacciinngg tthhee SSeeccoonndd BBiiaass TTrraannssffeerr RRoolllleerr
When the second bias transfer roller needs to be replaced, a message appears on the control panel.
1. Remove paper from the left tray, then fold up the tray.
2. To open Door A, lift the release lever, then open Door A.
WARNING: The area around the fuser can be hot. To avoid injury, use caution.
Caution: Do not touch the transfer belt. Touching the belt can reduce image quality or
damage the transfer belt. Do not touch the transfer roller. Touching the roller can reduce
image quality.
3. Remove the new transfer roller from the packaging. Retain the packaging.
Xerox
®
AltaLink
®
B81XX Series Multifunction Printer
User Guide
245
Maintenance
