Xerox ColorQube 9301 Evaluator Guide

Xerox ColorQube 9301/9302/9303 Evaluator Guide 19
Specifications
Device Management Xerox CentreWare
®
Web, Xerox CentreWare Internet Services, CentreWare for Tivoli
®
NetView
®
, CentreWare for Unicenter TNG
®
, CentreWare for Microsoft
Management Console (MMC), CentreWare for HP
®
OpenView
®
, Xerox Device Manager, Novell NDPS/NEPS, Xerox Device Types for SAP R/3 Environment.
Xerox SAP R/3 Intelligent Barcode Utility (optional), Xerox Barcode Pro PS (optional)
Operating Systems Microsoft
®
Windows
®
XP (32- and 64-bit), Windows Server 2003 (32- and 64-bit), Server 2008 (32- and 64-bit), Windows Vista (32- and 64-bit),
Windows 7 (32- and 64-bit)
Mac OS 10.5-10.6 (PostScript only)
Solaris 9, 10
HP UX 11, 11i
AIX 5
Linux RedHat Fedora Core 1-7
Linux RedHat Enterprise Linux 4
SUSE 10.X
UNIX (PPD only)
Citrix
Media Handling Supported
Sizes and Weights
Standard Trays:
•Trays1and2–550sheetseach,5.5x8.5in.SEFto11x17in.SEF(A5/148x210mmtoA3/297x420mm),16lb.bondto80lb.cover(60to220gsm)
•Tray3–2,100sheets,8.5x11in.LEF(A4/210x297mm),16lb.bondto80lb.cover(60to220gsm)
•BypassTray–100sheets,customsizesfromA5/8.5x5.5in./#10EnvelopeSEFtoSRA3/12x18in.SEF,16lb.bondto80lb.cover(60to220gsm)
Optional High-Capacity Feeder:
•4,000sheets,8.5in.x11in.(A4),16lb.bondto80lb.cover/120lb.index(60to220gsm)
High-Capacity Feeder Kits (HCF required):
•2,000-sheetShortEdgeKit,11x17in./A3,16lb.bondto80lb.cover(60to220gsm);or
•2,000-sheetLetter/Legal/A4ShortEdgeKit,16lb.bondto80lb.cover(60to220gsm)
Operating
Environment
Required Temperature Range: 50° to 90° F (10° to 32° C)
Required Relative Humidity: 5% to 85%
Electrical Power (North America): 110 to 127 VAC, 50/60 Hz
Power (Europe): 220 to 240 VAC, 50/60 Hz
Power Consumption:
• Running (Max): 120V: 1800 watts (15A); 230V: 2300 watts (10A)
• Running (Average): 750 watts
• Standby Mode: 350 watts
• Low Power Mode: 185 watts
• Sleep Mode: 105 watts
• ENERGY STAR
®
qualified
Warm-Up Time:
• From Low Power: 47 sec.; From Sleep: 3 min 30 sec.
•TheIntelligentReadypowermanagementfeaturelearnstheuniqueprintusagepatternsofanofcesothedevicewillbeinreadymodewhenneeded
and automatically go into lower power modes when not needed. This feature maximizes energy efficiency and results in pages being generated in as fast
as 7.2 seconds.
Dimensions
Width
Depth Height Weight
IOT with Offset Catch Tray
(OCT) 55 in. (1,398 mm) 28.4 in. (722 mm) 45.5 in. (1,156 mm) 501 lbs. (227 kg)
With OCT and High Capacity
Feeder 64 in. (1,618 mm) 28.4 in. (722 mm) 45.5 in. (1,156 mm) 567 lbs. (257 kg)
With Office Finisher 63 in. (1,601 mm) 28.4 in. (722 mm) 45.5 in. (1,156 mm) 562.2 lbs. (255 kg)
With High Volume Finisher 82.4 in. (2,093 mm) 28.4 in. (722 mm) 45.5 in. (1,156 mm) 687 lbs. (311.5 kg)
With High Volume Finisher
with Booklet Maker, Post
Process Inserter and Z-Fold/
C-Fold Unit
96.2 in. (2,443 mm) 28.4 in. (722 mm) 45.5 in. (1,156 mm) 813 lbs. (368.8 kg)
Agency Approvals FCC Class A Compliant (U.S.), DOC Class A Compliant (Canada)
CB Certified (IEC 60950-1/EN 60950-1)
2004/108/EC
2006/95/EC
99/5/EC
Windows Hardware Quality Labs
ENERGY STAR qualified
Full System Common Criteria (ISO 15408) certification (pending)
Section 3: Technical Specifications,
Supplies and Support Resources
Specifications

Xerox ColorQube 9301 Specifications

General

Brand	Xerox
Model	ColorQube 9301
Category	All in One Printer
Language	English
