Xerox DocuMate 6480 User Manual

Xerox
®
DocuMate
®
6460 / 6480 Scanner Setup
6 User Guide
4. Open the automatic document feeder cover and remove any tape or protective foam from
inside the feeder. Close the feeder cover when you are finished.
The above illustrations are for example purposes only. Your scanner’s packaging may vary slightly.
5. Slide the release switch in the output tray if you want it to lay flat on the desk.
Connect the Power Cord
Note: Only use the power supply (DA-48M24 made by APD) included with your scanner.
Connecting any other type of power supply may damage your scanner, and will void its warranty.
1. Plug the power supply into the power port on the scanner.
2. Plug the power cord into the power supply and into a wall outlet.

Xerox DocuMate 6480 Specifications

General

Media thickness (min)	1.25 mm
Maximum scan area (ADF)	216 x 5994 mm
Minimum scan area (ADF)	51 x 51 mm
Scanning media types supported	Photo paper, Plastic Card
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	75 - 90 g/m²
Scanner type	ADF scanner
Product color	Blue, White
Built-in display	Yes
Auto document feeder (ADF) input capacity	120 sheets
Film scanning	No
Maximum scan size	241 x 5994 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Output monochrome depth	1 bit
ADF scan speed (b/w, A4)	80 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (b/w, A4)	160 ipm
Sensor type	CCD
Scan drivers	ISIS, TWAIN, WIA
Daily duty cycle (max)	10000 pages
USB version	3.2 Gen 1 (3.1 Gen 1)
Standard interfaces	USB 3.2 Gen 1 (3.1 Gen 1)
Cables included	AC, USB
Minimum RAM	2048 MB
Minimum processor	Intel Pentium IV
Minimum storage drive space	350 MB
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Sustainability certificates	ENERGY STAR
Power supply type	AC
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	168 mm
Width	316 mm
Height	191 mm
Weight	4700 g
