DocuPrint P8ex User Guide
1-16
ENGLISH
Installing Memory
1
Turn off power and disconnect the power cable.
2
Remove two screws from back of control board, and pull control board
out of printer.
Be aware that
control board is
connected to
inside of printer by
two cables. Do not
disconnect these
cables.
3
Align SIMM with its connection points at control board’s connectors at a
70
o
angle.
4
Rotate SIMM downward into connector until it snaps into place. Make
sure both metal clips on connector are fastened and two pins on
connector are pushed through the holes in the SIMM.
5
Slide control board back into printer and
fasten with screws removed in Step 2.
Reattach cable(s) and power cord and
turn on printer.
