Xerox Phaser 6360 User Guide

Loading Paper
Phaser® 6360 Color Laser Printer
3-13
Setting Tray 1 (MPT) Mode
Tray 1 (MPT) Mode defines the printer’s media handling behavior to better fit the kind of
printing you want to do. Three distinct modes determine how paper type and size are set for
Tray 1 (MPT), and which tray is used if you do not select a specific tray:
Automatic (Factory Default): Tray 1 (MPT) is the highest priority tray. It allows incoming
print jobs to set paper type and size. It prints from Tray 1 (MPT) if paper is present at the start
of a job that does not select another tray.
Dynamic: The printer searches the trays to find the paper size and type to match your print job.
If no size or type matches are found in Trays 2-5, and Tray 1 (MPT) media size and type have
not been set on the printer’s control panel, the printer sets the paper type and size from the
print job, and then prints from Tray 1 (MPT).
Static: Set the paper type and size on the printer’s control panel so that the printer can
determine which tray contains the paper type and size each print job requires. The paper type
and size of your print job must match the Tray 1 (MPT) paper type and size settings on the
control panel (to print from Tray 1 (MPT).
Tray 1 (MPT) Mode controls two aspects:
■ Tray 1 (MPT) is used if paper is present in it (and no other tray is specified).
■ How the paper type and size are determined if not set from the control panel.
See also:
Advanced Features Guide at www.xerox.com/office/6360support
Using Manual Feed
If you are using paper, such as letterhead, and do not want others to use it by mistake, you can
set the printer to prompt you when it is time to load the paper for your print job.
Windows
To select manual feed using Windows 2000, Windows XP, or Windows Server 2003:
1. In the Windows printer driver, click the Paper/Quality tab.
2. Select Force Printing from a Specific Tray, and then select Tray 1 (MPT) from the list.
3. Select Manual Feed, and then click OK to save the driver settings.
4. Submit your print job.
5. When prompted by the control panel, remove the paper from Tray 1 (MPT).
6. Load the appropriate paper for your job into the tray.
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
