Xerox Phaser 6360 User Guide

Solving Print-Quality Problems
Phaser® 6360 Color Laser Printer
4-14
Printed Colors Do Not Match Monitor Colors
Problem
The color produced by the printer looks different from the color that appears on the monitor.
Solution
For more information about color matching between the monitor and the printed document,
see the Advanced Features Guide at www.xerox.com/office/6360support
.
PANTONE Colors Do Not Match
Problem
The colors printed on the document do not match the Phaser 6360 PANTONE color chart.
Solution
To match the document colors to the color chart:
■ If the application software allows the user to select a printer PPD file for printing a
document, make sure the Phaser 6360 PPD is selected. The PANTONE colors in the
printer are calibrated for the printer’s default halftone; overriding the printer’s default
halftone will change the printer’s color reproduction. For more information about software
settings for your applications, consult your application’s user manual.
■ Turning off other color matching software, such as ColorSync or ICM color matching,
when trying to match PANTONE Colors is recommended. Using other color matching
software while matching PANTONE Colors can cause unpredictable color output. If you
choose to use a Color Management software, set the printer’s color correction to none, and
do not use the printer specific charts.
■ To match PANTONE spot colors, select Properties, click the Color Options tab, select
Automatic color correction, click the Advanced button, and then select the Spot Colors
tab. For example, print documents using the None color correction if the PANTONE Color
chart was printed using none (the recommended setting). Also verify that the color’s
CMYK values match the CMYK values on the chart.
■ The printed PANTONE charts can fade over time or when exposed to sunlight. Check the
color charts you printed against the PANTONE Color swatch book available from
PANTONE, Inc. You may need to re-print the chart, especially if it has been exposed to
light for some time. Storing the charts in a dark place helps preserve the color.
■ Print a test page from your control panel to check the colors. If your printer has media that
is out of specification, or other supplies that are at the end of useful life, color adjustments
may not be able to get the printer to match PANTONE Colors.
See also:
Advanced Features Guide at www.xerox.com/office/6360support
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
