Xerox VersaLink B610 Security Guide

Xerox® Security Guide for Office Class Products: AltaLink®  VersaLink®
November 2018 Page 8
10/100/1000 MB Ethernet RJ-45 Network Connector
This is a standard RJ45 Ethernet network connector and confirms to IEEE Ethernet 802.3 standards.
Rear USB (Type B) Target port
A USB type B port located on the controller board at the rear of the product. This port supports the
following:
 USB target connector used for printing
Note: This port can be disabled completely by a system administrator.
Optional Equipment
RJ-11 Analog Fax and Telephone
The analog fax module connects to the controller. The fax connection supports the Fax Modem T.30
protocol only and will not accept data or voice communication attempts. An external (EXT) is available to
connect an external handset. In this configuration, the FAX card acts as a passive relay.
Wireless Network Connector
VersaLink® products accept an optional wireless module via a proprietary port.
AltaLink® products accept an optional wireless kit that can be installed in the rear USB port.
Near Field Communications (NFC) Reader
The system supports an installable RFID reader for authentication and convenience in certain
configurations. VersaLink® products accept the RFID reader via USB on the front of the product.
AltaLink® products come standard with an RFID reader built into the front panel. This communication
cannot write or change any settings on the system. The data exchanged is not encrypted and may
include information including system network status, IP address and product location. NFC functionality
can be disabled using the embedded web server of the product. NFC functionality requires a software
plugin that can be obtained from Xerox sales and support. NFC functionality is supported via optional
touch screen user interface or optional dedicated NFC USB dongle.
Information shared over NFC includes: IPv4 Address, IPv6 Address, MAC Address, UUID (a unique
identifier on the NFC client), and Fully qualified domain name
SMART CARD – CAC/PIV
All VersaLink® products support CAC/PIV login by enabling the VersaLink® Plug-in feature and then
enabling the appropriate plug-in. Additional plug-ins can be downloaded from Xerox.com in the product
Support area online.
All VersaLink® products support SIPR network access through a plug-in. The SIPR network plug-in is
restricted only to users who have purchased the SIPR kit from Xerox. Contact your Xerox sales
representative for details.
Foreign Product Interface
This port is used to connect optional equipment to control access to the machine. A typical application is
a coin-operated product where a user must deposit money to enable the machine to print. The
information available via the Foreign Product Interface is limited to optically-isolated pulses that can be
used to count impressions marked on hardcopy sheets. No user data is transmitted to or from this
interface.

Xerox VersaLink B610 Specifications

General

Package depth	640 mm
Package width	580 mm
Package height	610 mm
Package weight	28000 g
Country of origin	Vietnam
Maximum resolution	1200 x 1200 DPI
Optional connectivity	Wireless LAN
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Printing colors	Black
Maximum duty cycle	300000 pages per month
Number of print cartridges	1
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Average cartridge yield (black)	30000 pages
USB port	Yes
Color	No
Print technology	Laser
Warm-up time (from sleep mode)	35 s
Time to first page (black, normal)	3.7 s
Print speed (black, normal quality, A4/US Letter)	63 ppm
Duplex print speed (black, normal quality, A4/US Letter)	56 ppm
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	500 sheets
Custom media width	76.2 - 190 mm
Custom media length	216 - 356 mm
Duplex media weight	60 - 176 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 220 g/m²
Maximum ISO A-series paper size	A4
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP, HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP, FTP
Storage media	HDD
Internal memory	2048 MB
Processor cores	2
Processor family	ARM Cortex
Internal storage capacity	320 GB
Sound power level (standby)	27.1 dB
Sound pressure level (printing)	56.8 dB
Current rating	8 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	72 W
Power consumption (printing)	900 W
Control type	Touch
Product color	Blue, White
Market positioning	Business
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	AC
Compatibility	VersaLink B600/B610

Weight and Dimensions

Depth	465.5 mm
Width	427.4 mm
