Xerox VersaLink B610 Security Guide

Xerox® Security Guide for Office Class Products: AltaLink®  VersaLink®
November 2018 Page 23
Runtime Security
Each AltaLink® device comes with McAfee Embedded Control built-in and enabled by default. McAfee
Embedded Control is used to protect a variety of endpoints that range from wearable devices to critical
systems controlling electrical generation.
Executable control prevents unauthorized code from executing. Xerox has defined a whitelist of
executable programs; software that is not on the secure whitelist is not allowed to execute.
Memory control monitors memory and running processes. If unauthorized code is injected into a running
process, it is detected and prevented.
When an anomaly is detected it is logged to the device audit log and optional alerts are immediately sent
via email. Events are also reportable through CentreWare® Web or Xerox Device Manager, and
McAfee® ePolicy Orchestrator® (ePO).
Event Monitoring & Logging
Audit Log
The Audit Log feature records security-related events. The Audit Log contains the following information:
Field
Description
Index
A unique value that identifies the event.
Date
The date that the event happened in mm/dd/yy format.
Time
The time that the event happened in hh:mm:ss format.
ID
The type of event. The number corresponds to a unique description.
Description
An abbreviated description of the type of event.
Additional
Details
Columns 6–10 list other information about the event, such as:
Identity: User Name, Job Name, Computer Name, Printer Name, Folder Name, or
Accounting Account ID display when Network Accounting is enabled.
Completion Status
Image Overwrite Status: The status of overwrites completed on each job. Immediate
Image must be enabled.
AltaLink® products currently support 159 unique security events. VersaLink® products currently support
52 unique events.
A maximum of 15,000 events can be stored on the device. When the number of events exceeds 15,000,
audit log events will be deleted in order of timestamp, and then new events will be recorded. The audit
log be exported at any time by a user with administrative privileges. Note that as a security precaution,
audit log settings and data can only be accessed via HTTPS.
Operational Security
Firmware Restrictions
The list below describes supported firmware delivery methods and applicable access controls.
 Local Firmware Upgrade via USB port:
Xerox service technicians can update product firmware using a USB port and specially configured USB

Xerox VersaLink B610 Specifications

General

Package depth	640 mm
Package width	580 mm
Package height	610 mm
Package weight	28000 g
Country of origin	Vietnam
Maximum resolution	1200 x 1200 DPI
Optional connectivity	Wireless LAN
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Printing colors	Black
Maximum duty cycle	300000 pages per month
Number of print cartridges	1
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Average cartridge yield (black)	30000 pages
USB port	Yes
Color	No
Print technology	Laser
Warm-up time (from sleep mode)	35 s
Time to first page (black, normal)	3.7 s
Print speed (black, normal quality, A4/US Letter)	63 ppm
Duplex print speed (black, normal quality, A4/US Letter)	56 ppm
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	500 sheets
Custom media width	76.2 - 190 mm
Custom media length	216 - 356 mm
Duplex media weight	60 - 176 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 220 g/m²
Maximum ISO A-series paper size	A4
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP, HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP, FTP
Storage media	HDD
Internal memory	2048 MB
Processor cores	2
Processor family	ARM Cortex
Internal storage capacity	320 GB
Sound power level (standby)	27.1 dB
Sound pressure level (printing)	56.8 dB
Current rating	8 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	72 W
Power consumption (printing)	900 W
Control type	Touch
Product color	Blue, White
Market positioning	Business
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	AC
Compatibility	VersaLink B600/B610

Weight and Dimensions

Depth	465.5 mm
Width	427.4 mm
