Xerox Work Centre 7970i User Manual

Installation WorkCentre
®
7970 Series
Customer Expectation and Installation Guide 18
Installation Planning
Main Components
The WorkCentre 7970/7970i is delivered with Print Engine, Scanner
and Embedded Network Controller
Module Dimensions
Space Requirements / Service Space Envelope
Space Requirements / Service Space Envelope
The dimensions shown below provide the overall service space
required, including the space to the nearest obstruction. The
dimensions reflect both typical and hallway installations and are
absolute minimums.
7. Device Direct (DD) Communications:
Each device will need to be communicating to Xerox through the internet via the Xerox Device Direct method for Remote
Diagnostics support. Follow the steps below (customer) to find how to setup Device Direct, if required.
Setting up Device Direct:
A) Go to the “Support and Drivers” link on Xerox.com.
 Search for your product, then click on the Support link for that product.
 In the search field, enter "Enroll SMart eSolutions" and follow the instructions provided.
B) If the search does not return any instructions:
 Click on the Documentation link for your product.
 Open the System Administrators Guide and refer to the section of the guide which provides information regarding
Smart eSolutions Setup and follow the steps provided.
X
X
X
Dimensions and Weight
Configuration
Width
Depth
Height
Weight
Base
Configuration
25.2 in. /
640mm
27.5 in. /
699 mm
45.2 in. /
1,149.2
mm
334.2 Lbs
/ 151.9
Kgs
Base
configuration +
BR Finisher
51.3 in /
1302
mm
27.5 in. /
699 mm
45.2 in. /
1,149.2
mm
430.4 Lbs
/ 195.6
Kgs
Base
configuration
+ BR Booklet
finisher
56.4 in. /
1,431.4
mm
27.5 in. /
699 mm
45.2 in. /
1,149.2
mm
467.1 Lbs
/ 212.3
Kgs
Base
configuration
+ BR Booklet
finisher + C/Z
folder
65.5 in. /
1664.2
mm
28.6 in.
/726 mm
45.2 in. /
1,149.2
mm
581.7 Lbs
/ 264.4
Kgs
Base
configuration
+ BR Booklet
finisher + C/Z
folder + High
Capacity Feeder
77.9 in. /
1978.2
mm
28.6 in. /
726 mm
45.2 in. /
1,149.2mm
654.5 Lbs
/ 297.5
Kgs
Product Space Requirements
Configuration
Width
Depth
Height
Installation
Space
Base
Configuration
43.6 in /
1,107 mm
27.5 in /
699 mm
60.8 in /
1,546 mm
63.5” x 81.4”
1613 mm x
2067 mm
Base Config + BR
Finisher
69.9 in /
1,776 mm
27.5 in /
699 mm
60.8 in /
1,546 mm
90.2” x 81.4”
2220 mm x
2067 mm
Base Config + BR
Booklet finisher
72.3 in /
1,837 mm
27.5 in /
699 mm
60.8 in /
1,546 mm
92.6” x 81.4”
2352 mm x
2067 mm
Base Config+ BR
Booklet finisher +
C/Z folder
81.5 in /
2070.2
mm
28.6 in /
726 mm
60.8 in /
1,546 mm
101.8” x
81.4”
2586 mm x
2067 mm
Base Config + BR
Booklet finisher +
C/Z folder +High
Capacity Feeder
81.5 in /
2070.2
mm
28.6 in /
726 mm
60.8 in /
1,546 mm
101.8” x
81.4”
2586 mm x
2067 mm
