7
Installation
Step 1: Open the fan assembly
Step 2: Install the rear grille
Turn the front grille counterclockwise until it separates from
the rear grille. Remove the front and rear grille, then take out the
fan blade assembly.
11
12
13
Install the rear grille onto the motor with " " facing
upwards, and then install and turn the rear grille knob
clockwise to firmly fix the rear grille to the sha of the motor.
6
13
Step 3: Install the fan blade assembly
Align the center hole of the fan blade assembly with the
motor's sha to install it into position, then install the fan
blade assembly knob onto the motor's sha. Turn the knob
counterclockwise to fix the fan blade assembly to the motor's
sha.
12
5
11 12 13
２
6
13
12
5
