Xilinx MIcroBlaze Development Spartan-3E 1600E Kit User Manual

MicroBlaze Development Kit Spartan-3E 1600 Edition User Guide 133
UG257 (v1.1) December 5, 2007 www.xilinx.com
R
Appendix A
Schematics
This appendix provides the following circuit board schematics:
x “FX2 Expansion Header, 6-pin Headers, and Connectorless Probe Header”
x “RS-232 Ports, VGA Port, and PS/2 Port”
x “Ethernet PHY, Magnetics, and RJ-11 Connector”
x “Voltage Regulators”
x “FPGA Configurations Settings, Platform Flash PROM, SPI Serial Flash, JTAG
Connections”
x “FPGA I/O Banks 0 and 1, Oscillators”
x “FPGA I/O Banks 2 and 3”
x “Power Supply Decoupling”
x “XC2C64A CoolRunner-II CPLD”
x “Linear Technology ADC and DAC ”
x “Intel StrataFlash Parallel NOR Flash Memory and Micron DDR SDRAM ”
x “Buttons, Switches, Rotary Encoder, and Character LCD ”
x “DDR SDRAM Series Termination and FX2 Connector Differential Termination”
